reliable equipment operation, operating flexibility, adaptability, large capacity, wide range used in metallurgy, building materials, chemicals, coal, fertilizer, ore, sand, clay, kaolin, sugar, and other fields, the diameter : Φ1000-Φ4000, depending on the length and dried claims. In the center of the drum dryer broken up institutions to avoid increased, the wet into the dry cylinder body of the drum wall material is copied repeatedly took a board, Paola, in the process of falling were scattered broken device becomes fine particles, a significant increase in specific area, full contact with the hot air drying.
Widely used in alfalfa dried distillers dried, dried straw, sawdust and dried marigold drying, drying wood shavings, dried ginkgo leaves, dried herbs, dried brewer's grains, distillers grains and dried potato starch residue dried cassava residue dried malt dry, dried seeds, bagasse drying, dried hawthorn, rape seed cake drying, drying vegetables, thermal efficiency up to 80%, significantly higher than similar devices.

Model (mm)	Inclination (%)	Rotate speed (r/min)	Air inlet temperature (°C)	Power (kW)	Production capacity(t/h)	Weight(t)
600x6000	3-5	3-8	≤700	3	0.5-1.5	2.9
800x8000	3-5	3-8	≤700	4	0.8-2.0	3.5
800x10000	3-5	3-8	≤700	4	0.8-2.5	4.5
1000x10000	3-5	3-8	≤700	5.5	1.0-3.5	5.6
1200x10000	3-5	3-8	≤700	7.5	1.8-5	14.5
1200x12000	3-5	3-8	≤700	11	2-6	14.8
1500x12000	3-5	2-6	≤800	15	3.5-9	17.8
1800x12000	3-5	2-6	≤800	18	5-12	25
2200x12000	3-5	1.5-6	≤800	18.5	6-15	33
2200x18000	3-5	1.5-6	≤800	22	10-18	53.8
2200x20000	3-5	1.5-6	≤800	30	12-20	56
